Fortpro Relay Switch 12V 4 Pole 30 Amp Replacement for 965400001 | F235445
Specifications:
- Nominal Voltage: 12V
- Rated Continuous Load: 30A at 85° C
- Ambient Temperature: -40° C...+85° C
- Operating / Drop out Voltage: < 7.2V / > 1.2V
- Max. Coil Voltage: 18V
- Suppression: None
- Mechanical Cycles: 10,000,000
- Vibration: 20 - 200HZ, 5 g, no contact openings 10µs
- Terminals: 30, 85, 86: ISO 8092 6.3 x 0.8, CuZn, gal Sn 87: ISO 8092 6.3 x 0.8, CuZn
$4.60
Fortpro Relay Switch 12V 4 Pole 30 Amp Replacement for 965400001 | F235445—
$4.60
Description
Specifications:
- Nominal Voltage: 12V
- Rated Continuous Load: 30A at 85° C
- Ambient Temperature: -40° C...+85° C
- Operating / Drop out Voltage: < 7.2V / > 1.2V
- Max. Coil Voltage: 18V
- Suppression: None
- Mechanical Cycles: 10,000,000
- Vibration: 20 - 200HZ, 5 g, no contact openings 10µs
- Terminals: 30, 85, 86: ISO 8092 6.3 x 0.8, CuZn, gal Sn 87: ISO 8092 6.3 x 0.8, CuZn
